LS1 Camaro LS high mount Alternator Relocation Bracket LS1 LS2 LS6 SS Z28 GTO

Product image 1
Product image 2
Product image 3
Product image 4
Product image 5
Product image 6
Product image 7
Product image 8
Product image 9
Product image 10

LS1 Camaro LS high mount Alternator Relocation Bracket LS1 LS2 LS6 SS Z28 GTO

Camaro LS1 High Mount Alternator Bracket


  • This kit uses LS1 Camaro/Firebird crank pulley
  • Includes: bracket, idler pulley, tensioner, and mounting hardware
  • Can be used with standard (105amp) LS style alternators. (will not fit high amp truck (145/160amp) Corvette/CTSV or 2010-15 Camaro large bolt pattern alternators)
  • Made in Wichita, Kansas from aerospace grade, USA produced, billet aluminum
    • This kit uses USA made (belt tensioner, spacers, brackets)

Compatible with (based on vehicle 3D scans by ICT)

  • Nissan  350Z      03-08
  • Infiniti  G35        02-07

Belt lengths when used with:

  • 551523 775K6 with 105amp alt
  • 551785 775K6 with 105amp alt
  • 551581 763K6 with 105amp alt
  • 551776 730K6 with 105amp alt
$87.00

Original: $289.99

-70%
LS1 Camaro LS high mount Alternator Relocation Bracket LS1 LS2 LS6 SS Z28 GTO—

$289.99

$87.00

Product Information

Shipping & Returns

Description

Camaro LS1 High Mount Alternator Bracket


  • This kit uses LS1 Camaro/Firebird crank pulley
  • Includes: bracket, idler pulley, tensioner, and mounting hardware
  • Can be used with standard (105amp) LS style alternators. (will not fit high amp truck (145/160amp) Corvette/CTSV or 2010-15 Camaro large bolt pattern alternators)
  • Made in Wichita, Kansas from aerospace grade, USA produced, billet aluminum
    • This kit uses USA made (belt tensioner, spacers, brackets)

Compatible with (based on vehicle 3D scans by ICT)

  • Nissan  350Z      03-08
  • Infiniti  G35        02-07

Belt lengths when used with:

  • 551523 775K6 with 105amp alt
  • 551785 775K6 with 105amp alt
  • 551581 763K6 with 105amp alt
  • 551776 730K6 with 105amp alt
